FTTH 60mm length SC/APC Single Mode Fast Connector
Mechanical Splice - No need for Fusion Splice, Clamp & Polishing, No Expoxy
Quickly Field Assembly
Install Termination Time No More Than 60 seconds
Description
Quick Assembly Connector with unique mechanical splice V-groove
technology, can provide a fast, easy and stable termination of
fibers in the field. Both SC single-mode and multi-mode connector
options are available for 2.0x1.6mm, 3.1x2.0mm flat, and 3mm round
drop cable applications allowing the installer to terminate and
make the connection in 3 minutes in the field.
This connector system doesn’t need any requirements such as epoxy,
adhesive or costly curing ovens. Field installable SC connector
features that the installer can easily recognize the installation
status by simple termination tools.
The cable clamping method offers stable cable retention and
installer convenience. It reduces connection defect rate by
allowing re-assembling several times in the field without
additional tools.
Features
* Field installable, Cost-effective, User friendly
* No epoxy (adhesives), electrical power, and field polishing
required
* Quick and easy fiber termination in the field
* Visual indication of proper termination
* Reliable and superior optical performance
* SC/FC/LC type connectors available
* Reduced connection defect rate by re-assembling
* Compatible with 3.0mm round drop cable, 2.0x1.6mm and 3.1x2.0mm
flat cable
Specifications
| Model No. | FAOC2101-2-ASC | FAOC2101-2-USC | FAOC2101-2-USC |
| Connector type & Polish | SC/APC | SC/UPC | SC/UPC |
| Fiber type | Single Mode, 9/125μm, 250μm buffer coating, ITU-T G.652D / G.657A standard | 62.5/125μm or 50/125μm OM1, OM2, OM3, OM4 |
| Accommodating Cable | 3.1*2.0mm/1.6*2.0mm flat FTTH drop cable (Bow type or “8” type) and 3.0mm round cable |
| Cable Clamp | Alligator screw clip structure (Folding cable clamp and screw type
boot) |
| V-groove Holder | Push-pull ring for bare fiber clamping (Push forward to lock and
Pull back to release) |
| Fiber Stripping Length | φ0.25mm – 25mm (Buffer Coating Fiber) |
| Fiber Cleaving Length | φ0.125mm – 10mm (Bare Fiber) |
| Wavelength | 1310nm, 1490nm, 1550nm |
| Insertion loss | Typ.≤0.3dB (Max. 0.5dB) | Typ.<0.2dB (Max. 0.5dB) | Typ.<0.1dB (Max. 0.3dB) |
| Return loss | Typ.≥60dB (Min. 50dB) | Typ.≥50dB (Min. 40dB) | Typ.≥35dB (Min. 22dB) |
| Size | 62x8.9x7.3mm (w/ Dust Cap), 60x8.9x7.3mm (w/o Dust Cap) |
| Concentricity of Ferrule | ＜1.0μm |
| Inner Diameter of Ferrule | 125.3μm |
| Bare fiber fastening strength | ≥3N (ΔIL≤0.3dB) |
| Tensile strength | ≥20N (ΔIL≤0.3dB) |
| Connector Durability | ＜0.2dB (After 200 mating) |
| Operating temperature | -40 to 85°C |
| Success rate | >98% (for the first time) |
| Standard | Compliance with YD/T 2341.1-2011 specifications |
| Package | PE Bag or Blister Box, inner and outer carton, 10 pcs per Blister
box, 15x11.5x8.5cm and 0.45kg weight for 100 pcs 44x25x17cm and 5.10kg weight for 1000 pcs (Reference only) |
Accessories
| Name | Model No. | Description | Picture |
Drop Cable Holder
| DCH25-10 (350) | Also referred to as a guide jig or fixed-length cutting template,
used to fixed-length cleave |  |
| User Manual | Front | For SC/UPC or SC/APC Connector (Custom version is available) |  |
| Rear |  |
Notes:
1. Standard Configuration: 2pcs Drop Cable Holder, and 1pcs User
Manual for 100pcs Connector, if you need more, please contact our
sales representative.
2. The width of the Drop Cable Holder is 16.3mm, compliant with
Sumitomo brand fiber cleaver standard.
3. The default Fixed Cutting Length of Drop Cable Holder: Buffer
Coating Length - 25mm, Bare Fiber Length after Cutting - 10mm,
total fiber length without a jacket is 35mm (Buffer fiber + Bare
fiber), this is the most important part, if the length changes, the
splicing result maybe fail. *
4. For more details about how to use these accessories, please
check the User Manual.
Order Information
| Model No. | Description | Remarks |
| FAOC2101-2-ASC | Alligator screw clip, push-pull ring, SM, 60mm, for drop cable,
flat input, SC/APC | |
| FAOC2101-2-USC | Alligator screw clip, push-pull ring, SM, 60mm, for drop cable,
flat input, SC/UPC | |
| FAOC2101-2-USC | Alligator screw clip, push-pull ring, OM2, 60mm, for drop cable,
flat input, SC/UPC | |
