    ZTE 1.244Gbps 1GE+3FE+CATV GPON ONU

    Ask Lasest Price
    Brand Name : Yogel or OEM
    Model Number : GPON ONU 1GE+3FE+CATV
    Certification : ISO9000
    Price : Negotiate
    Payment Terms : Western Union, MoneyGram, T/T, L/C
    Supply Ability : 10000 pcs/ month
    Delivery Time : 3-5 days after despoit
    • Product Details
    • Company Profile

    ZTE 1.244Gbps 1GE+3FE+CATV GPON ONU

    1GE+3FE+CATV GPON ONU ONT fiber optic onu ont pon modem working with ZTE gpon onu router


    1. Overview

    1GE+3FE+CATV type ONT products fully comply with ITU-T G.984 GPON standards.. It is operative, manageable and maintainable at telecommunication level, and can provide high speed data service for customers. It has a PON uplink port that connects to office end apparatus through optical fiber.

    2. Features
    ◼ Single-fiber access, providing Data, CATV and other services
    ◼ Dual mode, full compatible with ITU-T G.984 or IEEE 802.3ah
    ◼ Support Web for local management
    ◼ Support Auto-negotiation and MDI/MDIX
    ◼ Support the Ethernet interface rate, working mode and flows control
    ◼ Support packet filtering and anti-illegal message attack protection
    ◼ Support DHCP Option60 reporting the location information of the Ethernet interface

    ◼ Support for IPv4 and IPv6 dual stacks
    ◼ Support OAM/OMCI for remote management
    ◼ Fully compatible with Huawei, Fiberhome, and ZTE OLT

    3. Hardware Parameter
    ItemParametersSpecification





    PON

    PON Port1 GPON Optical Interface:SC/UPC
    Rate

    Upstream:1.244Gbps

    downstream:2.488Gbps

    TypeBOSA
    WavelengthTx 1310nm, Rx 1490nm

    Optical Output

    Power


    +0.5~+5dBm

    Sensitivity-28dBm
    Overload-8dBm

    UNI


    LAN

    1*10/100/1000Mbps and 3*10/100Mbps

    Full / Half-Duplex, RJ45, Auto-MDI/MDI-X





    Environmental Specifications

    ShellPlastic casing
    PowerExternal DC 12V/1A power supply adapter

    Power

    consumption


    <5W

    Dimensions172mm(L)*130mm(W)*30mm(H)
    Weight<0.3kg

    Environment

    Operating Temperature:0~50℃

    Storage Temperature:-40~85℃ Operating Humidity:10%~90%


    4. Functions

    GPON Feature

    Compliant with ITU-T G.984 GPON standard
    FEC (Forward Error Correction) in both upstream and downstream Dynamic bandwidth status report
    802.1p mapper for upstream
    QoS scheduling based on SP or WRR between GEM port and T- CONT

    OAM Feature
    Standard OMCI compliant with ITU-T G.988
    Compliant with TR-069 standard
    Compliant with TR-098,TR-140
    Remote software upgrade through
    EPON OAM Feature
    CTC 3.0 standard of China Telecom
    Remote software upgrading through OAM
