Feature:

• Fiber type (specify size, material): 40/48/55, quartz
• NA:0.22
• Single fiber attenuation:≦1 dB/m
• Number of fibers:271
• Device length: 3m (split beam length 0.5m)
• Arrangement: Hexagonal Dense Pile Array
• Duty Cycle:52%
• Split strategy:1:7
• Closed End Connector: Standard SMA905
• Split-end connector.:Standard SMA905
• Closed end face size: hexagonal with side length 0.459mm
• Split bundle end face dimensions: 6 pcs φ0.385; 1pcs φ0.05
• Channel Yield:≥99%
• Yield rate of channels within 4 circles of the center: 100%

Application:

*Silicon photonics field

*PIC coupling application

*Grating coupling applications

*High-efficiency coupling of small mode spot laser chips

*Non-dimmable high-efficiency coupling

*Resistant to reflow soldering applications

*High power applications
